Electric Bikes
Adventure
Adventure Electric Bike from EcoBike
Imported from Asia
|
|
An enhanced frame design is the hallmark of the Adventure, which easily accommodates the more demanding rider. It is built to handle both the pavement and off-road trails. The elegant lines and classic aesthetics ensure every trip is made in style.
Adventure Specifications:
Frame Style: Cross Bar
Frame Size: Fits 5'2"-6'5"
Wheel Size: 26"
Frame: Aluminium Alloy 6061/T6 Giant
Colors: Dark BlueGrey
Motor Power: 360 watt (700 peak)
Motor Type: Brushless, Geared
System Voltage: 36V
Battery Type: Li-MnO
Battery Capacity: 10Ah
Battery Weight: 9.1 lbs
Controller: Adjustable Electronic
Power Range: Up to 25 miles (In pedal assist mode: depends
on rider weight, terrain, road conditions, and human effort)
Top Speed: 20 mph (Top power speed limited by national law)
Drive: DirectDrive Rear Hub
|
Riding Modes: Traditional/PAS/Throttle Only
Gross Weight: 52 lbs
Gears: 6 Speed
Derailluer: Shimano Tourney
Gear Shift: Shimano Twist Revo Shift
Throttle: Twist Grip
Brakes Front: SRAM Avid V-Brake
Brakes Rear: SRAM Avid V-Brake
Suspension: Front Forks and Seat Post
Rim: 26" Double Wall Aluminum
Tire: Kenda K-Sheild 1.75" - Thorn Resistant Tubes -
Puncture-Resist Liners
Seat Post: Suspension
Fenders: P-Flex
Rear Rack: 50 lb max. with elastic straps
Front Light: 5 LED
Rear Light: Hi-Vis Blinking
|
|
The EcoBikes
Battery Power
The Lithium-Ion Manganese battery power pack is lightweight, technologically advanced, and safe. EcoBike battery packs are UL and CE approved, exceeding safety and quality standards in the U.S. and E.U. EcoBike batteries are specially designed and manufactured for the EcoBike by a subsidiary of Lenovo / IBM ThinkPad. These batteries deliver the maximum consistent output and longevity. EcoBike batteries have been tested and proven, with over 100,000 units manufactured and a failure rate of less than 1%.
Drive Motor
The EcoBike is powered by an innovative hub-mounted, brushless permanent magnet motor with a triple planetary gear drive system and proprietary heat resistant materials. The propulsion system delivers the highest torque and is the quietest in its class. The drive motor is nominally rated for continuous output at 360 watts (Elegance & Adventure) and 290 watts (Vatavio). Each gear in the motor is individually cut by precision CNC machinery, and each motor is hand wound and tested, ensuring the highest quality. Operating an EcoBike is virtually silent, with no emissions.
Electronic Control
The Zero-Smart-Start speed controller delivers ease of use and smooth drive control and offers a multi-function variable speed output. It is state of the art, producing consistent efficient power between the battery and motor. The automatic Pedal Assist mode produces a power burst that dramatically assists the pedaling effort. The Zero-Smart-Start electronic throttle system allows the rider to relax and not pedal at all. EcoBikes are the only electric bikes to offer Pedal Assist, Zero-Smart-Start throttle, and the on/off switch all on the handgrip.
Frame Geometry
EcoBike electric bikes have been specially designed with the daily commuter in mind. The frame is constructed from a high-strength, lightweight 6061 aluminum alloy that maximizes safety and durability. The enhanced frame design features comfort ergo-geometry that is more upright than a traditional mountain or road bike. This keeps the back straighter and relieves stress on the shoulders, arms, and back. The cycling experience is enhanced because longer distances can be achieved with less fatigue. Every EcoBike electric bike is outfitted with suspension, front forks (except Vatavio), and seat post, delivering a smoother ride.
|
|
BionX PL-350

PL-350 Electric Motor Kit from BionX - sample bike installation
Made in Canada
|
|
BionX makes the best motor kits in the world. Energy is provided in proportion to the torque applied to the pedals. Pedal harder and get a stronger and faster assistance. Pedal lightly and receive gentle, gradual assistance. Stop pedaling and your assistance automatically cuts off. Each pedal stroke is analyzed separately by a microprocessor, equalizing your energy so you can concentrate on enjoying a smooth, powerful and precise ride.
The BionX System consists of a console, a battery and a special wheel-based motor.
The PL-350 provides high torque for climbing, long rides and fast accelerations. It outfitted with a down tube battery mounting unit or on a new and practical rear rack version, to suit all frames and riders.
Motor: 350 Watts
Average Range: 90 km
Battery: 36,9V- LiMn – 10 Ah
Weight: 7.7 kg (motor and battery pack)
|
BionX PL-500
PL-500 Electric Motor Kit from BionX - sample bike installation
Made in Canada
|
|
BionX makes the best motor kits in the world. Energy is provided in proportion to the torque applied to the pedals. Pedal harder and get a stronger and faster assistance. Pedal lightly and receive gentle, gradual assistance. Stop pedaling and your assistance automatically cuts off. Each pedal stroke is analyzed separately by a microprocessor, equalizing your energy so you can concentrate on enjoying a smooth, powerful and precise ride.
The BionX System consists of a console, a battery and a special wheel-based motor.
The PL-500 provides a unique and compact 500 watt motor that can go up to 45 km/h (where permitted by law). The ultimate machine.
Motor: 500 Watts
Average Range: 60 km
Battery: 36,9V- LiMn – 10 Ah
Weight: 7.7 kg (motor and battery pack)
|
Elegance
Elegance Electric Bike from EcoBike
Imported from Asia
|
|
The Elegance combines European styling with an upright design to offer an easy, comfortable ride. The Elegance’s 26” wheels increase stability and ease of handling, while the step-through frame makes getting on and off a breeze. The enhanced motor on the Elegance electric bike increases the range of travel on a single charge to 25 miles in pedal assist mode. (Based on a 150-pound cyclist riding on flat ground) The Elegance is the ideal electric bike for the rider who prioritizes comfort and ease of use.
Elegance Specifications:
Frame Style: Step-Thru
Frame Size: Fits 5'0"-6'5"
Wheel Size: 26"
Frame: Aluminium Alloy 6061/T6 Giant
Colors: Brushed Aluminum or Matte Black or White
Motor Power: 360 watt (700 peak)
Motor Type: Brushless, Geared
System Voltage: 36V
Battery Type: Li-MnO
Battery Capacity: 10Ah
Battery Weight: 9.1 lbs (9.8) lbs
Controller: Adjustable Electronic
Power Range: Up to 25 miles (In pedal assist mode: depends
on rider weight, terrain, road conditions, and human effort)
Top Speed: 20 mph (Top power speed limited by national law)
Drive: DirectDrive Rear Hub
|
Riding Modes: Traditional/PAS/Throttle Only
Gross Weight: 52 lbs
Gears: 6 Speed
Derailluer: Shimano Tourney
Gear Shift: Shimano Twist Revo Shift
Throttle: Twist Grip
Brakes Front: SRAM Avid V-Brake
Brakes Rear: SRAM Avid V-Brake
Suspension: Front Forks and Seat Post
Rim: 26" Double Wall Aluminum
Tire: Kenda K-Sheild 1.75" - Thorn Resistant Tubes -
Puncture-Resist Liners
Seat Post: Suspension
Fenders: P-Flex
Rear Rack: 50 lb max. with elastic straps
Front Light: 5 LED
Rear Light: Hi-Vis Blinking
|
|
The EcoBikes
Battery Power
The Lithium-Ion Manganese battery power pack is lightweight, technologically advanced, and safe. EcoBike battery packs are UL and CE approved, exceeding safety and quality standards in the U.S. and E.U. EcoBike batteries are specially designed and manufactured for the EcoBike by a subsidiary of Lenovo / IBM ThinkPad. These batteries deliver the maximum consistent output and longevity. EcoBike batteries have been tested and proven, with over 100,000 units manufactured and a failure rate of less than 1%.
Drive Motor
The EcoBike is powered by an innovative hub-mounted, brushless permanent magnet motor with a triple planetary gear drive system and proprietary heat resistant materials. The propulsion system delivers the highest torque and is the quietest in its class. The drive motor is nominally rated for continuous output at 360 watts (Elegance & Adventure) and 290 watts (Vatavio). Each gear in the motor is individually cut by precision CNC machinery, and each motor is hand wound and tested, ensuring the highest quality. Operating an EcoBike is virtually silent, with no emissions.
Electronic Control
The Zero-Smart-Start speed controller delivers ease of use and smooth drive control and offers a multi-function variable speed output. It is state of the art, producing consistent efficient power between the battery and motor. The automatic Pedal Assist mode produces a power burst that dramatically assists the pedaling effort. The Zero-Smart-Start electronic throttle system allows the rider to relax and not pedal at all. EcoBikes are the only electric bikes to offer Pedal Assist, Zero-Smart-Start throttle, and the on/off switch all on the handgrip.
Frame Geometry
EcoBike electric bikes have been specially designed with the daily commuter in mind. The frame is constructed from a high-strength, lightweight 6061 aluminum alloy that maximizes safety and durability. The enhanced frame design features comfort ergo-geometry that is more upright than a traditional mountain or road bike. This keeps the back straighter and relieves stress on the shoulders, arms, and back. The cycling experience is enhanced because longer distances can be achieved with less fatigue. Every EcoBike electric bike is outfitted with suspension, front forks (except Vatavio), and seat post, delivering a smoother ride.
|
|
Izip Via Express
Izip Via Express Electric Bike from Currie Technologies
Made in Asia
|
|
This is one of the fastest bikes currently on the market, with the longest range, as well as attractive styling. It features all new Currie Evo-Drive™ 2.0 technology, a patented dual-planetary drive system that blends the power of a hi-torque 750 watt electric motor — and a 36 volt, 18 ampere-hour battery pack — with your human power to create one of the highest performance electric bikes available today. The mid-frame, removable system provides superior balance, lower center of gravity, and superior handling to other performance eBikes.
Top Speed: 20+ mph / 32+ km/h
Range: 31 miles / 50 km
|
Izip Via Rapido
Izip Via Rapido Folding Electric Bike from Currie Technologies
Made in Asia
|
|
The best combination of power, range, and price in a step-through model. It is equipped with strong and light 700 C wheels, 35 C street treads with Slime® puncture-resistant inner tubes. It has an easily removable lithium-ion battery pack, front suspension fork, and Velo® comfort saddle. The Via Rapido is designed specifically for commuters and sport riders with an integrated pedal assist system.
Top Speed: 20 mph / 32 km/h
Range: 15-22 Miles / 24-35 km
|
Izip Via Urbano
Izip Via Urbano Electric Bike from Currie Technologies
Made in Asia
|
|
A small, folding cycle with capacity to hold cyclists from around 50 inches to over 6 feet, in a beautiful design. Lightweight, powerful and perfectly equipped for urban transportation. The hidden, removable in-frame ion battery pack is paired with the Currie Electro-Drive system, which is the perfect solution for short trips. It easily folds to carry on a bus, or store in a car, boat or plane.
Top Speed: 15 mph / 24 km/h
Range: 12 Miles / 20 km
|
Vatavio
Vatavio Electric Bike from EcoBike
Imported from Asia
|
|
Vatavio Electric Bike folding from EcoBike
|
|
The Vatavio is a convenient, space-saving alternative to the conventional electric bicycle. It is the only folding electric bike on the U.S. market that boasts a Shimano gear system for enhanced drivability and control. The Vatavio electric bike folds down in less than 10 seconds, and comes complete with a carrying bag. Weighing 48.6 pounds with battery, the Vatavio can be easily stored in an office, boat, RV, plane, closet, or car trunk. For riders of public transportation or air travel, your bike is a simple carry-on. It comes fully assembled and ready for use.
Vatavio Specifications:
Frame Style: Folding (35"x17"x29" folded)
Frame Size: Fits 4'11-6'4"
Wheel Size: 20"
Frame: Aluminium Alloy 6061/T6 Giant
Colors: Raw Aluminum
Motor Power: 290 watt (600 peak)
Motor Type: Brushless, Geared
System Voltage: 36V
Battery Type: Li-MnO
Battery Capacity: 8Ah
Battery Weight: 8.4 lbs
Controller: Adjustable Electronic
Power Range: Up to 20 miles (In pedal assist mode: depends on rider weight, terrain, road conditions, and human effort)
Top Speed: 20 mph (Top power speed limited by national law)
Drive: DirectDrive Rear Hub
Riding Modes: Traditional/PAS/Throttle Only
Gross Weight: 49 lbs
Gears: 6 Speed
Derailluer: Shimano Tourney
Gear Shift: Shimano Twist Revo Shift
Throttle: Twist Grip
Brakes Front: SRAM Avid V-Brake
Brakes Rear: SRAM Avid V-Brake
Suspension: Seat Post
Rim: 20" Double Wall Aluminum
Tire: Kenda K-Sheild 1.75" - Thorn Resistant Tubes - Puncture-Resist Liners
Seat Post: Suspension
Fenders: P-Flex
Rear Rack: 50 lb max. with elastic straps
Front Light: 5 LED
Rear Light: Hi-Vis Blinking
|
|
